Fujitsu Fujitsu 7.0kW Multi Head Wall Mounted Split System Air Conditioner ASTG24LFCC

Indoor Unit ASTG24LFCC with Outdoor Unit AOTG30LBTA4

Multi head Air Conditioning systems are designed where one outdoor unit can work with multiple indoor units.

Fujitsu 7.0kW Multi Head Wall Mounted Split System Air Conditioner ASTG24LFCC

One outdoor unit can be connected to a wide variety of indoor units, including wall mounted, consoles, cassette and ducted units. Each room can be individually controlled, allowing you to set different temperatures in each room, helping save running costs by heating or cooling rooms as required. The benefit of a multi head systems also helps increase valuable space where having separate splits will take up more room.

The range includes 6 different indoor unit types and 14 different models ranging in capacity from 2.3kW to 6.8kW. With such a wide range of options to choose from, there's a combination to suit almost any need from a small apartment to a large family home.

Up/Down Swing Louvre
The up/down louvre automatically swings up and down.

Auto Shut Louvre
The auto shut louvres close or open automatically when the unit stops or starts.

Auto Restart
Should there be temporary loss of power; the unit will automatically restart itself in the same operating mode, once the power is restored.

Program Timer
This timer allows selection of one of four options. ON, OFF, ON > OFF, or OFF > ON.

Economy mode
Limits the maximum operation current, and performs operation with the power consumption suppressed.

ON-OFF Timer
ON-OFF timer can be set to operate once every 24 hours.

Automatic Louvre
The position of the louvres is set automatically to match the operating mode. It is also possible to adjust the louvres using the remote control.

Automatic Air Flow Adjustment
When auto mode is selected for the fan, the micro-processor adjusts the airflow to follow changes in room temperature.

Sleep Timer
The micro-processor gradually changes the room temperature, allowing you to sleep comfortably at night.

Washable Panel
Unit has a washable panel

Filter sign
Indicates the filter cleaning period by lamp.

ALL DC
With All DC, electricity loss is decreased and power consumption reduced.

Specification

Model No. - Indoor
ASTG24LFCC
Model No. - Outdoor
AOTG30LBTA4
Reverse Cycle System
Yes
Cooling Capacity (Watts)
6,800
Cooling Capacity (BTU/h)
23,223
Range (Watts)
7,400
Range (BTU/h)
25,272
Heating Capacity (Watts)
8,200
Heating Capacity (BTU/h)
28,004
Range (Watts)
9,000
Range (BTU/h)
30,736
Power Supply (Volts)
240
Phase-Frequency (Ph - Hz)
1-50
Power Supply Attachment
Outdoor
Running Current, Cooling (Amps)
0.53
Running Current, Range (Amps)
0.53
Input (Watts)
69
Fan Speed
4
Air Circulation, High (l/s)
311
Compressor Type
Twin Rotary
Dimensions - Inside Unit (HxWxD Mm)
320x998x238
Weight - Inside Unit (kg)
14
Dimensions - Outside Unit (HxWxD Mm)
830x900x330
Weight - Outside Unit (kg)
68
I.U. Sound Pressure Level (dBA@1mtr)
49
O.U. Sound Pressure Level (dBA@1mtr)
50
O.U. Sound Power Level (dBA)
64
Refrigerant Type
R410A
Connection Pipe Sizes, Gas (mm)
15.88
Connection Pipe Sizes, Liquid (mm)
6.35
Minimum Pipe Length (Metre)
5
Maximum Pipe Length (Metre)
25
Maximum Pipe Height (Metre)
10
Pipe Connection Methods
Flare
Outdoor Operating Temp, Cooling Degrees C
0 to 46
Outdoor Operating Temp, Heating Degrees C
-15 to 24
